Mobile Charging Robot
Autonomous mobile charging equipment for commercial, park & garage scenarios
Integrated autonomous mobile charging equipment combining storage cells, smart charging system and movable chassis. No fixed charging pile or wiring required — remotely controlled autonomous movement and automatic alignment charging for parking lots, automaker parks, commercial EV operations and overseas commercial charging.
Series Lineup
| Model | Capacity | Voltage | Power | Dimensions (mm) | Weight | Thermal | Cycle Life | Standards |
|---|---|---|---|---|---|---|---|---|
GB-55ACNEW Mobile Charging Car · 55.3 kWh | 55.3 kWh | 460.8 V | 40 kW | 1125×663×1080 mm | 567 kg | High-rate low-heat cells (no complex thermal system) | 4,000 cycles @70-80 SOH | GB 6.3 / EN 8.19 |
GB-106AC Mobile Charging Robot · 106 kWh | 106 kWh | 460.8 V | 80 kW | 1826×854×1395 mm | 1200 kg | Independent air-conditioning system | 6,000 cycles @70-80 SOH | GB 139000 |
GB-150AC01 Mobile Charging Robot (US) · 144.7 kWh | 144.7 kWh | 460.8 V | 80 kW | 1826×854×1395 mm | 1400 kg | Air cooling + PTC heating | — | GB 149000 / EN 193700 |
GB-150AC02NEW Mobile Charging Robot · 156.7 kWh | 156.7 kWh | 499.2 V | 80 kW | 2232×960×1510 mm | 1500 kg | Liquid cooling & heating | — | GB 167000 / EN 217100 |
GB-200AC Mobile Charging Robot (US) · 192.9 kWh | 192.9 kWh | 614.4 V | 120 kW | 2060×965×1435 mm | 1700 kg | Air cooling + PTC heating | — | GB 185000 |
209ACNEW Mobile Charging Robot · 209 kWh | 209 kWh | 665.6 V | 120 kW | 2232×960×1510 mm | 1800 kg | Liquid cooling & heating | — | GB 217000 / EN 279000 |
GB-55ACNEW
Highlight: Lightest & most compact in the series (567 kg). High-rate low-heat cells require no complex thermal system — lower energy use, higher safety, minimal maintenance.
Applications: Private home garages, small enterprise parks, dense parking spots, daily EV top-up and emergency power.
GB-106AC
Highlight: Cost-effective workhorse for commercial fleets. Dedicated A/C keeps constant temperature year-round — no power derating in extreme heat or cold.
Applications: Commercial parking lots, automaker test tracks, park public charging, routine fleet maintenance.
GB-150AC01
Highlight: North America edition — fully matched to US grid standards and vehicle protocols. Air+PTC dual thermal handles wide day-night temperature swings.
Applications: US commercial parking, automaker operations, overseas park smart charging.
GB-150AC02NEW
Highlight: 499.2 V high voltage for newer high-voltage EVs. Liquid thermal boosts heat dissipation by 30%+ — supports 24/7 nonstop charging without derating.
Applications: Large commercial complexes, batch fleet maintenance, high-frequency nonstop charging.
GB-200AC
Highlight: US premium edition — 614.4 V ultra-high voltage matches North American high-end EVs, 120 kW for dramatically shorter charge times.
Applications: US premium commercial lots, luxury EV maintenance, high-end automaker testing.
209ACNEW
Highlight: Flagship of the robot series — 209 kWh + 120 kW dual top specs. 665.6 V covers every EV on the market; unattended smart charging around the clock.
Applications: Large EV industrial parks, super parking hubs, 24/7 unattended commercial stations.
Key Features
Global protocol compatibility
VIN auto-identification, multi-gun parallel charging, PV input, grid recharge and inverter output. Compatible with GBT / CCS1 / CCS2 and other global standards.
High efficiency & energy saving
Charging efficiency up to 97% and storage efficiency up to 92%. Precise voltage/current regulation minimizes charge-discharge loss for long-term energy savings.
Full-scenario safety protection
Full-range IP54 dust & water resistance. Adapts to high/low temperature, high altitude and humid environments for stable operation across complex sites.
Flexible deployment without infrastructure
No fixed charging pile or trenching required. Self-moving chassis enables zero-cost deployment across unlimited scenarios.
Long lifespan & low maintenance
Up to 6000 cell cycles @70-80 SOH. Multiple thermal management options protect cells, lowering failure rate and OPEX over lifetime.
Representative Specifications
* Aggregate values span the full series. See the model-by-model table above for exact per-model specifications.
