Vehicle-Mounted Energy Storage Charging System
Customized onboard energy storage charger for engineering vehicles
Customized vehicle-integrated energy storage charging equipment built for excavators and other engineering vehicles as well as outdoor on-board storage scenarios. Fixed on-board installation, adapts to complex construction-site conditions, supports dual PV & grid recharge — the core energy storage device for engineering work in grid-less outdoor sites.
Series Lineup
| Model | Capacity | Voltage | Power | Dimensions (mm) | Weight | Thermal | Cycle Life | Standards |
|---|---|---|---|---|---|---|---|---|
GB-47DLNEW Excavator Storage Charger (EU) · 47 kWh | 47 kWh | 460.8 V | 40 kW | 1390×1028×1020 mm | 709 kg | Air conditioning + PTC heating | 4,000 cycles @70-80 SOH | GB 76000 / EN 98800 |
GB-106DL Excavator Storage Charger · 106 kWh | 106 kWh | 460.8 V | 80 kW | 1900×854×675 mm | 1050 kg | Air conditioning + PTC heating | 6,000 cycles @70-80 SOH | GB 130000 / EN 169000 |
GB-153DL On-board Energy Storage Charging System · 153 kWh | 153 kWh | 665.6 V | 80 kW | 1900×854×1030 mm | 1720 kg | Air conditioning + PTC heating | 6,000 cycles @70-80 SOH | GB 150000 |
GB-209DLNEW On-board System (Indonesia) · 209 kWh | 209 kWh | 665.6 V | 120 kW | 2088×960×1265 mm | 1820 kg | Liquid cooling & heating | — | GB 207000 / EN 265000 |
GB-418DLNEW On-board Energy Storage Charging System · 418 kWh (up to 700 kWh) | 418 kWh (upgradable to 700 kWh) | 665.6 V | 240 kW | 2400×1400×1700 mm | 3679 kg | Liquid cooling & heating | — | GB 380000 / EN 457000 |
GB-47DLNEW
Highlight: Lightweight entry model — only 709 kg, compact for small excavators and light vehicles without adding onboard load. EU-compliant with smart identification and multi-gun parallel charging.
Applications: European small engineering vehicles, light excavators, off-grid temporary construction and field work.
GB-106DL
Highlight: Value benchmark — longest 6,000-cycle life in its class slashes O&M cost. Slim 675 mm-thick body fits most medium engineering vehicles; dual GB/EN standards cover domestic and export use.
Applications: Medium excavators at home & abroad, long-term site operation, PV-based outdoor recharging.
GB-153DL
Highlight: High-voltage large-capacity upgrade — 665.6 V matches high-voltage machinery that low-voltage units cannot serve; 153 kWh sustains long continuous operation.
Applications: Domestic large engineering machinery, high-frequency sites, long uninterrupted off-grid construction.
GB-209DLNEW
Highlight: Indonesia edition for hot-humid climates. 120 kW fast charging plus a 105 kW bidirectional AC/DC module — PV inversion and grid recharge far beyond standard models.
Applications: Indonesian heavy engineering vehicles, hot-humid outdoor sites, rapid charging for large equipment.
GB-418DLNEW
Highlight: Flagship of the onboard series — switchable 418/700 kWh capacity for flexible range extension. Highest 240 kW power charges multiple heavy machines simultaneously; full-condition liquid thermal.
Applications: Super-heavy machinery, multi-vehicle cluster operations, large overseas projects, long off-grid construction.
Key Features
Engineering-vehicle customization
Customized onboard integration for excavators and other heavy engineering vehicles. Fixed on-board installation adapts to construction-site vibration, dust and harsh conditions.
Dual PV & grid recharge
Supports photovoltaic input and grid recharge for continuous energy supply in off-grid outdoor construction sites.
High-voltage & high-capacity scaling
Voltage range from 460.8V up to 665.6V, capacity from 47 kWh to 418 kWh (upgradable to 700 kWh) to match equipment from light excavators to super-heavy machinery.
Regional compliance variants
GB-47DL EU edition, GB-209DL Indonesia edition — precisely matched to local grid, equipment standards and extreme-climate conditions for seamless export compliance.
Long lifespan & low maintenance
Up to 6000 cell cycles @70-80 SOH. Air-cooling + PTC heating or liquid-cooling & liquid-heating thermal options protect cells for stable high-frequency construction duty.
Representative Specifications
* Aggregate values span the full series. See the model-by-model table above for exact per-model specifications.
